By focusing on the future, Patriot
has expanded the product line to offer transmit/receive antenna
systems as well as receive-only products. The antennas currently
hold various type approvals, and each antenna conforms to the FCC
29-25 Log Theta sidelobe envelope. In addition to these type
approvals, Patriot manufactures the only Ka/Ka TX/RX antenna systems
that has been type-approved by Eutelsat at Ka-Band

Sky Satellite Network is an official Patriot
Master Distributor stocking currently the following transmit/receive
(VSAT) antennas, available from our warehouse in Germany
|
Ka-Band Antennas
|
| Sky Satellite Network Ref. |
Description |
Data Sheet (pdf)
Manual (pdf)
|
| |
|
|
| AN-PE090A |
0.9 m Single
Optics Ka-Band, Tx/Rx Antenna, Linear Polarization, Eutelsat
approval |
|
| AN-PF120A |
1.2m Single
Optics, Ka-Band,Tx/Rx Antenna, Linear Polarization, FCC
compliance |
|
| |
|
Ku-Band Antennas
|
| Sky Satellite Network Ref. |
Description |
Data Sheet (pdf)
Manual (pdf)
|
| |
|
|
| AN-PI120K |
1.2 m Single
Optics Ku-Band, Tx/Rx Antenna, Intelsat approval |
|
| AN-PE120K |
1.2m Dual
Optics, Ku-Band,Tx/Rx Antenna, Eutelsat approval |
|
| AN-PI180K |
1.8m Single
Optics, Ku-Band Intelsat approval |
|
| AN-PE180K |
1.8m Dual
Optics, Ku-Band, Tx/Rx Antenna, Eutelsat approval pending |
|
| AN-PF240K |
2.4 m Single
Optics, Ku-Band, Tx/Rx Antenna, FCC compliance |
|
| AN-PE240K |
2.4 m Dual
Optics, Ku-Band, Tx/Rx Antenna, Intelsat, Eutelsat, Asiasat
approval |
|
| |
|
C-Band Antennas
|
| Sky Satellite Network Ref. |
Description |
Data Sheet (pdf)
Manual (pdf)
|
| |
|
|
| AN-PI180C |
1.8 m Single
Optics, C-Band Circular, Tx/Rx Antenna, Intelsat approval |
|
| AN-PF240C |
2.4 m Single
Optics C-Band Circular, Tx/Rx Antenna, FCC compliance |
|
| AN-PF240L |
2.4 m Single
Optics, C-Band, Linear Tx/Rx Antenna, FCC compliance |
|
| AN-PE240C |
2.4 m Dual
Optics, C-Band Circular, Tx/Rx Antenna, Intelsat, Eutelsat,
Asiasat approval |
|
| AN-PE240L |
2.4 m Dual
Optics, C-Band Linear, Intelsat, Eutelsat, Asiasat approval |
|
| TX
Port of all C-Band Antennas: CPR 137 Waveguide Interface or
N-Connector, please specify |
|
